- General Information
- Manufacturer
- Speco Technologies
- Manufacturer Website Address
- http://www.specotech.com
- Brand Name
- Speco
- Product Type
- Ethernet Switch
Features
Our PoE switch series is designed to supply power and maximize network safety, with features of surge protection, weather-resistance and VLAN.
- VLAN Mode:
- When the VLAN mode is selected, each PoE port is isolated and independently connects with cameras, computers or other switches, while the uplink port connects with a router.
- The VLAN Function helps avoid broadcast storms and ARP spoofing.
- Surge Protection: Each port is equipped with a surge absorber which can survive under 10,000V/150A, nanosecond response time, matches with TVS diode to limit voltage spikes and eliminates surges to protect the device.
- PoE supplies power through the IEEE802.3af standard, with maximum 0.65A and overcurrent protection.
- Easy to install with an attached bracket.
- Compact design with waterproof features.
- Power supply included
- Interfaces/Ports
- Total Number of Network Ports
- 5
- Uplink Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 5 x Gigabit Ethernet PoE
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- Fast Ethernet
- Network Technology
- 10/100Base-T
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.3x
- IEEE 802.1Q
- IEEE 802.3af
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3z
- IEEE 802.3ab
- Power Description
- PoE (RJ-45) Port
- Yes
- Input Voltage
- 48 V DC
- 57 V DC
- Power Source
- Power Supply
- Power Consumption
- 75 W
- Physical Characteristics
- Form Factor
- Compact
- Standalone
- Height
- 12"
- Width
- 8.7"
- Depth
- 2"
- Miscellaneous
- Package Contents
- P4S5O Ethernet Switch
- Power supply
- Application/Usage
- Network
