TSC is excited to introduce its first series of 2" wide thermal transfer desktop printers. The TTP-225 Series of desktop thermal transfer printers brings TSC quality, innovation, performance, reliability and value to the small footprint 2" wide printer market.
The TTP-225 Series delivers premium performance for most retail, medical and office applications at an affordable price. The TTP-225 features a user friendly clamshell design with a large 5" OD center biased media capacity. Designed with no losable parts, it is the perfect size when you need a space-saving printer for 2" wide labels or tags. Simply open the cover and drop your labels into the printers spring loaded media guide. Top of form sensing by gap, black mark, or notch is standard and completely adjustable from side to side.
Choose either standard 203 dpi or higher resolution 300 dpi solutions. The TTP-225 features 203 dpi resolution and print speeds up to 5 inches per second. The 300 dpi TTP-323 is ideal for 2-D barcodes, fine text and small graphics labeling.
The TTP-225 is the first low cost thermal transfer compact 2" desktop printer to offer an optional LCD display to its customers. The LCD is used to present important information about print job status and setup which brings a new level of ease of use to its customers. Other outstanding features include an inexpensive internal Ethernet adapter for easy integration into network systems, cutters, label present sensor, and an optional keyboard for printing labels in stand-alone or down-time situations.
- Retail Point-of-Sale
- Oil Change & Auto Service Labeling
- Pharmacy Prescription Labeling
- Healthcare Specimen Labeling
- Healthcare Patient Tracking
- Shelf Labeling
- Product Marking
- Inventory & Asset Management
- Small Office/Home Office Mailing
- File-Folder Labeling
- Wristbands
- General Information
- Manufacturer
- TSC Auto ID Technology Co., Ltd
- Manufacturer Website Address
- http://www.tscprinters.com
- Brand Name
- TSC Auto ID
- Product Series
- TTP-225
- Product Type
- Direct Thermal Printer
- Technical Information
- Recommended Use
- Label Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 5 in/s
- Maximum Print Resolution (dpi)
- 203
- Maximum Print Length
- 90"
- Maximum Print Width
- 2.13"
- Application/Usage
- Desktop
- Print Technology
- Direct Thermal
- Memory
- Standard Memory
- 8 MB
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- Media Types & Handling
- Media Type
- Notch
- Wristband
- Continuous Roll
- Die-cut Label
- Black Mark
- Fanfold
- Maximum Roll Diameter
- 5"
- Maximum Label Width
- 2.36"
- Maximum Label Length
- 90"
- Power Description
- Power Source
- AC Supply
- Physical Characteristics
- Height
- 7"
- Width
- 5.5"
- Depth
- 9.5"
- Weight (Approximate)
- 5.40 lb
- Miscellaneous
- Platform Supported
- Mac
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Restriction of Hazardous Substances (RoHS)
