Buy Eaton Tripp Lite Series Duplex Multimode 50/125 Fiber Patch Cable (LC/SC), 3M (10 ft.)

Eaton Tripp Lite Series Duplex Multimode 50/125 Fiber Patch Cable (LC/SC), 3M (10 ft.)

Part: 1272762

$24.95

Availability

Out of Stock

General Information
- Manufacturer
- Tripp Lite by Eaton
- Manufacturer Website Address
- https://tripplite.eaton.com/
- Brand Name
- Tripp Lite by Eaton
- Product Type
- Network Cable

Tripp Lite's 3-meter multimode duplex Fibre Channel SC/LC patch cable is manufactured from 50/125 zipcord fiber. The cable has SC connectors on one end, and LC at the other, a PVC jacket, and is FDDI and OFNR rated. 50/125 Duplex multimode fiber is most commonly used in Fibre Channel applications. It is backward compatible with 62.5 micron fiber and built-in headroom for future applications. The cable provides higher bandwidth optimized for Gigabit and 10Gbps networks as well. Also available in 1, 2, 5, 10, 15, 20, 30, and 50 meter lengths. Search "N516-" to bring up all lengths. Also search "N506-" for SC-SC cables, and "N520-" for LC-LC cables. Tripp Lite warrants this product to be free from defects in materials and workmanship for life.

More from the Manufacturer

Warranty
- Limited Warranty
- Lifetime

Technical Information
- Cable Type
- Fiber Optic
- Cable Characteristic
- Patch Cable
- Core/Cladding Diameter
- 50/125 µm
- Cable Length
- 10 ft
- Connector Type on First End
- LC - Male
- Connector on First End Details
- 2 x LC - Male
- Connector Type on Second End
- SC Network - Male
- Connector on Second End Details
- 2 x SC Network - Male

Physical Characteristics
- Color Family
- Orange
- Product Color
- Orange
- Jacket Material
- Polyvinyl Chloride (PVC)

Miscellaneous
- Package Contents
- - Duplex Fibre Channel Patch Cable
  - 3M Duplex MMF Cable LC/SC 50/125 Fiber
- Additional Information
- - Number of fibers: 2
  - Primary coating diameter: 245+/-15 microns
  - Primary coating material: Acrylate
  - Secondary coating diameter: 900+/-50 microns
  - Numeric apeture: .275 nominal
  - Proof test level: 100,000 PSI
  - Insertion loss testing performed on every connector (0.2db typical) and provided with cable
  - Beveled edge on ends of glass makes insertion of plug a breeze
  - Color coded/labeled connectors
  Applications:
  - Gigabit
  - 10Gbps networks
  - Fiber and fibre channel installations
- Compatibility
- - Network Interface Card Fiber optic card requiring multimode duplex cable with LC/SC connectors
- Certifications & Standards
- - FDDI
  - OFNR
- Country of Origin
- China
