Megapixel resolution
DW's technology delivers crystal-clear images in resolutions up to 5MP over coaxial infrastructure. Higher resolution delivers forensic details when zooming into the camera's field of view.
Star-Light Plus™ color in darkness technology
Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.
Universal HD over Coax® Technology
Universal HD over Coax® Complete Solutions are the best way to upgrade an existing analog system to high-definition. Universal HD over Coax® cameras and recorders can transmit HD-Analog, HD-TVI, HD-CVI signals up to 4K, and analog signals to 960H.
- General Information
- Manufacturer
- Digital Watchdog
- Manufacturer Website Address
- http://www.digital-watchdog.com
- Brand Name
- Digital Watchdog
- Product Line
- Star-Light Plus
- Product Type
- Surveillance Camera
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 70 ft
- Night Vision Type
- Infrared
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/2.8"
- Color Supported
- Color
- Field of View
- Horizontal Field of View (HFOV) 82° Vertical Field of View (VFOV) 60°
- Effective Camera Resolution
- 5 Megapixel
- Video
- Maximum Video Resolution
- 2592 x 1944
- Maximum Frame Rate
- 30 fps
- Analog Video Signal Format
- HD-TVI
- HDCVI
- CVBS
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 4 mm
- Lens Included
- Yes
- Exposure
- Shortest Shutter Speed
- 1/30000 Second
- Longest Shutter Speed
- 1/30 Second
- Network & Communication
- Connectivity Technology
- Wired
- Power Description
- Input Voltage
- 12 V DC
- Power Source Type
- DC
- Physical Characteristics
- Form Factor
- Bullet
- Durability
- Dust Resistant
- Water Resistant
- Weather Resistant
- Color Family
- White
- Product Color
- White
- Height
- 6.4"
- Weight (Approximate)
- 1.10 lb
- Environmental Conditions
- Minimum Operating Temperature
- -4°F (-20°C)
- Maximum Operating Temperature
- 122°F (50°C)
- Maximum Operating Humidity
- 90%
- Miscellaneous
- Features
- Wide Dynamic Range
- 3D Digital Noise Reduction
- Day/Night
- Defog
- Built-in OSD Function
- Built-in Joystick
- Auto Gain Control
- Automatic White Balance
- Back Light Compensation (BLC)
- Mirror
- Privacy Masking
- Ingress Protection Rating
- IP66
- Country of Origin
- Vietnam
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
