IVA Analytics
MEGApix IVA cameras have a powerful engine to detect and classify people and vehicles in real-time. IVA+ license upgrade offers advanced video content analysis detection capabilities.
Logical Rules
Logical Rules combine multiple zones and virtual tripwires linked together for a greater event detection level while reducing unwanted false alarms/positives.
IVA integrates seamlessly with DW Spectrum IPVMS
MEGApix IVA analytics are seamlessly integrated with DW Spectrum IPVMS for easy configuration, real-time alerts and automatic notifications.
Reduce false alarms
MEGApix IVA's intelligent algorithms offer better object classification and identify environmental elements. The result is a substantial reduction in false alarms for control room operators and security personnel. By allowing only valid events to filter through MEGApix IVA cameras increase efficiency, productivity and cut unnecessary costs.
Star-Light Plus color in darkness technology
Star-Light Plus color in near-total darkness technology provides crisp, clear images in the absence of ambient light.
Cold Start -40°F (-40°C)
The installed heater helps the camera power up in extreme cold weather conditions where temperatures may go as low as -40°F. This makes the cameras ideal for any harsh environment installation.
- General Information
- Manufacturer
- Digital Watchdog
- Manufacturer Website Address
- http://www.digital-watchdog.com
- Brand Name
- Digital Watchdog
- Product Line
- MEGApix IVA
- Product Type
- Network Camera
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 140 ft
- Night Vision Type
- Infrared
- Display & Graphics
- Image Sensor Type
- CMOS
- Color Supported
- Color
- Field of View
- HFOV / VFOV 85° - 31° / 62° - 24°
- Effective Camera Resolution
- 5 Megapixel
- Video
- Video Formats
- H.264
- H.265
- MJPEG
- Maximum Video Resolution
- 2592 x 1944
- Maximum Frame Rate
- 30 fps
- Analog Video Signal Format
- CVBS
- Lens
- Lens Type
- Varifocal
- Minimum Focal Length
- 2.70 mm
- Maximum Focal Length
- 13.50 mm
- Lens Included
- Yes
- Maximum Aperture
- f/1.4
- Optical Zoom
- 5x
- Exposure
- Shortest Shutter Speed
- 1/32000 Second
- Longest Shutter Speed
- 1/15 Second
- Network & Communication
- Connectivity Technology
- Wired
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Power Description
- Input Voltage
- 12 V DC
- Power Source Type
- DC
- PoE
- Physical Characteristics
- Form Factor
- Bullet
- Durability
- Weather Resistant
- Dust Resistant
- Water Resistant
- Color Family
- White
- Product Color
- White
- Weight (Approximate)
- 1.98 lb
- Environmental Conditions
- Minimum Operating Temperature
- -40°F (-40°C)
- Maximum Operating Temperature
- 122°F (50°C)
- Maximum Operating Humidity
- 90%
- Miscellaneous
- Features
- Mirror
- Auto Flip
- Wide Dynamic Range
- Auto Gain Control
- Automatic White Balance
- PTZ
- Cross Line Detection
- Tamper Detection
- Day/Night
- Back Light Compensation (BLC)
- Motion Detection
- Defog
- Ingress Protection Rating
- IP66
- Country of Origin
- Vietnam
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
