- General Information
- Manufacturer
- Digital Watchdog
- Manufacturer Website Address
- http://www.digital-watchdog.com
- Brand Name
- Digital Watchdog
- Product Line
- MEGApix CaaS
- Product Type
- Network Camera
MEGApix CaaS all-in-one series of IP cameras combine the cameras with the ease and power of DW Spectrum IPVMS and onboard storage up to 1TB. DW Spectrum IPVMS server is pre-installed and licensed. No additional server hardware is required. The 5MP fisheye camera offers 360° Smart IR and a 1.55mm fisheye lens in an IP66-rated discrete vandal housing. Combine the CaaS solution with the Blackjack NAS device for long-term storage needs.
Features
- All-in-one cameras, no server required
- 5MP 1/1.8" image sensor at real-time 30fps
- 1.5mm fisheye lens
- Built-in 512GB and 1TB storage options for up to 60 days retained video*
- Support 360° hemispheric fisheye view and 360°, 180° and 90° panoramic views
- Edge-to-edge image clarity Easily to deploy with pre-loaded DW Spectrum IPVMS for out-of-the-box operation
- 24/7 access to live and recorded video feed
- Automatic installation and licensing with first power on
- Connect up to 30 MEGApix CaaS edge cameras
- Dual recording option with Blackjack NAS appliance
- Dual codecs (H.264, MJPEG) with simultaneous dual-stream
- 55' Smart IR with intelligent camera sync
- Smart DNR 3D digital noise reduction
- True day/night with mechanical IR cut filter
- Programmable privacy zones
- Auto gain control (AGC)
- Backlight compensation (BLC)
- Auto white balance (AWB)
- Motion detection Web server built-in
- PoE class 3 and DC12V
- Waterproof cabling
- UL listed
- ONVIF conformant, profile S
- NDAA compliant
- IP66 environmental-rated dust-tight and water-resistant
- 5 year warranty
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 55 ft
- Night Vision Type
- Infrared
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/1.8"
- Color Supported
- Color
- Field of View
- 360°
- Effective Camera Resolution
- 5 Megapixel
- Video
- Video Formats
- H.264
- MJPEG
- Maximum Video Resolution
- 2592 x 1944
- Maximum Frame Rate
- 30 fps
- Analog Video Signal Format
- CVBS
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 1.55 mm
- Lens Included
- Yes
- Maximum Aperture
- f/2.5
- Exposure
- Shortest Shutter Speed
- 1/32000 Second
- Longest Shutter Speed
- 1/30 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet Technology
- Fast Ethernet
- Protocols
- HTTP
- HTTPS
- SSL
- DNS
- DDNS
- DHCP
- FTP
- SMTP
- ICMP
- SNMPv1/v2c/v3 (MIB2)
- TLS
- AutoIP
- ZeroConf
- ONVIF
- TCP/IP
- UDP
- RTP/UDP
- RTP/TCP
- RTSP
- NTP
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Input Voltage
- 12 V DC
- Power Source Type
- DC
- PoE
- Physical Characteristics
- Form Factor
- Fisheye
- Durability
- Dust Resistant
- Water Resistant
- Weather Resistant
- Color Family
- White
- Product Color
- White
- Weight (Approximate)
- 1.10 lb
- Environmental Conditions
- Minimum Operating Temperature
- -4°F (-20°C)
- Maximum Operating Temperature
- 122°F (50°C)
- Maximum Operating Humidity
- 90%
- Miscellaneous
- Features
- Auto Gain Control
- Day/Night
- 3D Digital Noise Reduction
- Privacy Masking
- HTTPS Encryption
- Video Management System
- SD Card Local Storage
- Multi-crop Streaming
- Built-in IR LED
- Motion Detection
- Indoor/Outdoor
- Indoor
- Ingress Protection Rating
- IP66
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
