Megapixel resolution
DW's technology delivers crystal clear images in any resolution. Higher-resolution offers forensic details with zooming into the camera's field of view.
Video tampering detection - abnormal color detection
When the camera's color reproduction is changed, an event notification will be sent.
Line crossing
Once a pre-defined line is crossed from either direction, an event notification will be sent.
Perimeter intrusion
Once a pre-defined area is set, any crossing of the lines towards the area, out of the area, or both, will trigger an alarm.
Video tampering detection - scene change
When the camera is moved, and the Field of View (FoV) is different, an event notification will be sent.
Video tampering detection - video blur
When a sudden blur or loss in visibility is detected, an event notification will be sent.
True Wide Dynamic Range (WDR)
Cameras with True Wide Dynamic Range (WDR) technology have advanced sensors that can process a wider range of lighting, dark and bright in the same image.
- General Information
- Manufacturer
- Digital Watchdog
- Manufacturer Website Address
- http://www.digital-watchdog.com
- Brand Name
- Digital Watchdog
- Product Line
- MEGAPIX
- Product Type
- Network Camera
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 164 ft
- Night Vision Type
- Infrared
- Display & Graphics
- Image Sensor Type
- CMOS
- Color Supported
- Color
- Field of View
- 95.1° ~ 30°, 92°~31°
- Effective Camera Resolution
- 5 Megapixel
- Video
- Video Formats
- H.264
- H.265
- Motion JPEG
- Maximum Video Resolution
- 2592 x 1944
- Maximum Frame Rate
- 60 fps
- Lens
- Lens Type
- Varifocal
- Minimum Focal Length
- 2.80 mm
- Maximum Focal Length
- 12 mm
- Lens Included
- Yes
- Maximum Aperture
- f/1.4
- Optical Zoom
- 4.3x
- Exposure
- Shortest Shutter Speed
- 1/100000 Second
- Longest Shutter Speed
- 1/30 Second
- Network & Communication
- Connectivity Technology
- Wired
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Input Voltage
- 12 V DC
- Power Source Type
- DC
- PoE
- Physical Characteristics
- Form Factor
- Turret
- Durability
- Water Proof
- Dust Resistant
- Impact Resistant
- Weather Resistant
- Color Family
- White
- Product Color
- White
- Height
- 5.2"
- Width
- 4.1"
- Weight (Approximate)
- 1.45 lb
- Environmental Conditions
- Minimum Operating Temperature
- -22°F (-30°C)
- Maximum Operating Temperature
- 60°F (15.6°C)
- Maximum Operating Humidity
- 95%
- Miscellaneous
- Features
- Wide Dynamic Range
- Built-in IR LED
- Cross Line Detection
- Auto Gain Control
- Day/Night
- 3D Digital Noise Reduction
- Automatic White Balance
- Motion Detection
- Back Light Compensation (BLC)
- SD Card Local Storage
- Impact Protection Rating
- IK10
- Ingress Protection Rating
- IP67
- Country of Origin
- United States
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
