The Dell Analog KVM switches, engineered by Avocent, are ideally suited for environments where remote access is not required but maximum security is essential. The Analog Server Console Switch is an excellent choice where real-time video an
- Add a digital channel via a physical hardware key
- Local console USB
- Widescreen support
- Hi-res to 1600 x 1200 (standard) and 1680 x 1050 (widescreen)
- ACI support for cascading up to 256 servers
- Dell ReadyRails mounting interface
- General Information
- Manufacturer
- Dell Technologies
- Manufacturer Website Address
- http://www1.ca.dell.com
- Brand Name
- Dell
- Product Type
- Ethernet Switch
- Warranty
- Limited Warranty
- 3 Year
- Interfaces/Ports
- Total Number of Network Ports
- 8
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 8 x Gigabit Ethernet KVM RJ-45 Network Port
- 1 x USB Type A Port
- 1 x VGA Port
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 1000Base-T
- Maximum Data Transfer Rate
- 125 MB/s
- Network & Communication
- Layer Supported
- 2
- Management & Protocols
- Manageable
- Yes
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Power Source
- Power Supply
- Power Consumption
- 20 W
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Height
- 9.21" (234 mm)
- Width
- 1.72" (43.70 mm)
- Depth
- 17.01" (432 mm)
- Weight (Approximate)
- 2.99 kg
- Miscellaneous
- Application/Usage
- Server
- Certifications & Standards
- FIPS 140-2
- TAA Compliant
- Yes
