Cambium Networks cnPilot e501S IEEE 802.11ac 1.14 Gbit/s Wireless Access Point

  • Part: 2800121
$821.00

Availability

Out of Stock

Perfect for demanding, high density applications and longer range coverage across large areas, including: industrial or education campuses, enterprise and hospitality complexes, public parks and recreational areas, or just about any demanding outdoor environment requiring costeffective, controller managed WLAN access points.

THE CNPILOT WI-FI NETWORK HIGHLIGHTS

Operational superiority- The e501S with integrated sector antenna supports 256 client associations, 16 SSIDs, WPA-2 encryption, Dynamic VLANs, DFS channels, Access Control Lists (ACL), and more. The 802.11ac e501S is the essential workhorse for today's demanding, high density outdoor Wi-Fi networks.

High performance Wi-Fi network - All cnPilot's Enterprise access points (APs) support features like controller-less roaming, dynamic channel selection, automatic transmit power control, band steering, and more - essential features for easy Wi-Fi operations.

Mesh Rapidly setup multi-hop mesh networks either dedicating one radio (e.g.: 5 GHz) for mesh backhaul, or using both bands for client access simultaneously.

Wireless Backhaul Integration- the aux PoE port onthe e501S offers PoE out, eliminating the need for a second power line perfect for powering on a standard 802.3af camera, or on Cambium's PMP 450 or ePMP backhaul subscriber modules (SMs) for wireless backhaul enabled Wi-Fihotspots.

Resilience - Dual on-board Active/Standby memory banks ensure higher availability. The e501S can store two versions of the software - defaulting to a working operational software if needed - reducing the likelihood of site visits and increasing network up-time. Standard 3 year Warranty included, for peace of mind

  • General Information
    • Manufacturer
    • Cambium Networks
    • Manufacturer Website Address
    • http://www.cambiumnetworks.com
    • Brand Name
    • Cambium Networks
    • Product Line
    • cnPilot
    • Product Type
    • Wireless Access Point

  • Technical Information
    • Wireless LAN Standard
    • IEEE 802.11ac
    • Frequency Band
    • 2.40 GHz
    • 5 GHz
    • Wireless Transmission Speed
    • 1.14 Gbit/s
    • MIMO Technology
    • Yes
  • Interfaces/Ports
    • Ethernet Technology
    • Gigabit Ethernet
    • Number of Network (RJ-45) Ports
    • 2
    • PoE (RJ-45) Port
    • Yes
    • PoE PD Port
    • Yes
  • Physical Characteristics
    • Form Factor
    • Wall Mountable
    • Height
    • 11.81" (300 mm)
    • Width
    • 8.03" (204 mm)
    • Depth
    • 2.56" (65 mm)
    • Weight (Approximate)
    • 1.30 kg
