Perfect for demanding, high density applications and longer range coverage across large areas, including: industrial or education campuses, enterprise and hospitality complexes, public parks and recreational areas, or just about any demanding outdoor environment requiring costeffective, controller managed WLAN access points.
THE CNPILOT WI-FI NETWORK HIGHLIGHTS
Operational superiority- The e501S with integrated sector antenna supports 256 client associations, 16 SSIDs, WPA-2 encryption, Dynamic VLANs, DFS channels, Access Control Lists (ACL), and more. The 802.11ac e501S is the essential workhorse for today's demanding, high density outdoor Wi-Fi networks.
High performance Wi-Fi network - All cnPilot's Enterprise access points (APs) support features like controller-less roaming, dynamic channel selection, automatic transmit power control, band steering, and more - essential features for easy Wi-Fi operations.
Mesh Rapidly setup multi-hop mesh networks either dedicating one radio (e.g.: 5 GHz) for mesh backhaul, or using both bands for client access simultaneously.
Wireless Backhaul Integration- the aux PoE port onthe e501S offers PoE out, eliminating the need for a second power line perfect for powering on a standard 802.3af camera, or on Cambium's PMP 450 or ePMP backhaul subscriber modules (SMs) for wireless backhaul enabled Wi-Fihotspots.
Resilience - Dual on-board Active/Standby memory banks ensure higher availability. The e501S can store two versions of the software - defaulting to a working operational software if needed - reducing the likelihood of site visits and increasing network up-time. Standard 3 year Warranty included, for peace of mind
- General Information
- Manufacturer
- Cambium Networks
- Manufacturer Website Address
- http://www.cambiumnetworks.com
- Brand Name
- Cambium Networks
- Product Line
- cnPilot
- Product Type
- Wireless Access Point
- Technical Information
- Wireless LAN Standard
- IEEE 802.11ac
- Frequency Band
- 2.40 GHz
- 5 GHz
- Wireless Transmission Speed
- 1.14 Gbit/s
- MIMO Technology
- Yes
- Interfaces/Ports
- Ethernet Technology
- Gigabit Ethernet
- Number of Network (RJ-45) Ports
- 2
- PoE (RJ-45) Port
- Yes
- PoE PD Port
- Yes
- Physical Characteristics
- Form Factor
- Wall Mountable
- Height
- 11.81" (300 mm)
- Width
- 8.03" (204 mm)
- Depth
- 2.56" (65 mm)
- Weight (Approximate)
- 1.30 kg
